INVT VS070QS-1618MDM1

VS070QS-1618MDM1 Integrated Machine Product overview
202403 (V1.0) 7
Specification
VS070QS-1618MDM1
relay
Special
auxiliary relay
512 points (SM0–SM511)
State relay
1024 points (S0–S1023)
Timer
256 (T0–T255)
Note2
Counter
256 (C0–C255)
Note 3
Data register
10000 (D0–D9999)
Local data
register
64 (V0–V63)
Indexing
register
16 (Z0–Z15)
Special data
register
512 (SD0–SD511)
Interrupt
resources
External input
interrupt
16 (interruption triggering edges can be defined
by users, corresponding to the rising and falling
edges of the X0 to X7 terminals)
High-speed
counter
interrupt
6
Internal timed
interrupt
3
Serial port
interrupt
12
Interruption
after PTO
output
4
Interruption at
power outage
1
Communication
function
Communication
port
Three asynchronous serial communication ports:
Communication port 0: RS232
Communication port 1: RS485
Communication port 2: RS485
One Ethernet port: LAN port on the shell
Communication
protocol
Modbus, free-port, N:N (INVT proprietary
protocol, which can be applied to form 1:N or
N:N communication networks)
Special
function
High-speed
counter
X0, X1
Single input: 50 kHz
Simultaneous inputs of X0 to X5:
