VS 070 Q S-16 18 M D M 1
Non-standard product number. The non-standard product increases or
decreases special functions based on the standard product in chronological
order, such as 1, 2,…, A, B…(the mainstream module is by default)
Output mode
(R: Relay output; T: Transistor output; M: Mixture output of relay and
transistor; N: No output.)
Power input mode
(D: 24 V DC power input; A: 220 V AC power input; N: No external power
input.)
Unit type
M: Main module of the PLC; E: Expansion modules of the PLC.
Number of output points (18 output points in the example)
Number of input points (16 input points in the example)
Communication ports
E: Serial port; S: Ethernet port
Subseries
Q: Subseries, VS-Q series is full name
Display screen dimensions (the dimension of the display screen in the
example is 7.0'')
VS: VS series integrated machine
