INVT VS070QS-1618MDM1

VS070QS-1618MDM1 Integrated Machine Mechanical installation
202403 (V1.0) 22
3 Mechanical installation
3.1 Installation environment requirements
The integrated machine is applicable to scenarios with installation environments of
standard II and pollution level of 2.
Item
Specifications
IP rating
IP20
Pollution level
Level 2: Generally there is only non-conductive pollution,
but you shall consider transient conductivity accidentally
caused by condensation.
Altitude
2000m (80kPa)
Overcurrent
protection device
1.1A fuse
Max. working
temperature
45°C in full load
Derating is required when the ambient temperature is 55°C.
For details, see Figure 2-2.
Storage temperature
and humidity range
Temperature: -20℃–60℃
RH < 90%, without condensation
Transportation
temperature and
humidity range
Temperature: -40℃–70℃
RH < 95%, without condensation
Working temperature
and humidity range
Temperature: -20℃–55℃
RH < 95%, without condensation
3.1.1 Dimensions and specifications
Model
Length
Width
Height
Net weight
VS070QS-1618MDM1
203mm
145mm
56.45mm
800g
3.1.2 Installation method
Ensure that the power cable, PLC output module, contactor, starter, relay, and other
types of electrical interface devices keep a certain distance from the VS series
products when installing devices behind the product.
Note: What calls for special attention is that a longer distance should be kept
between the variable-frequency klystron and the switching power supply. Besides,
input and output of this kind of device must adopt shielded cables, and connect the
shielded net to the star-shaped ground of the system.
