INVT VS070QS-1618MDM1

VS070QS-1618MDM1 Integrated Machine Product overview
202403 (V1.0) 6
The rounded port on the left side is a port for downloading. Elliptic port is the mode
selection switch, providing three options: ON, TM, and OFF. For details about ports
on the right side, see port description.
2.3 Product specifications
2.3.1 Basic parameters
Specification
VS070QS-1618MDM1
Resolution (pixel)
800×480
Contrast
400: 1
Brightness
450cd/m
2
Touch panel
4-wire high precision touchpad
Display color
16.77 million
Backlight module
LED
Total number of I/O points
34
Number of input points
16
Number of output points
18
Analog input
2
Analog output
1
RS485 (One for HMI, and one for
PLC)
2
RS232
1
I/O
configuration
Max. I/O points
256 points (theoretical value)
Number of
expansion
modules
The total number of I/O expansion modules and
special modules is not more than 3.
User file
capacity
User program
capacity
32k steps
Data block size
10000 D elements
Command
speed
Basic command
0.2μs/command
Application
command
μs~hundred μs/command
Number of
commands
Basic command
32
Application
command
234
Soft element
resources
Note5
Input/output
points
128 inputs/128 outputs (inputs X0–X177, outputs
Y0–Y177)
Note1
Auxiliary relay
2048 points (M0–M2047)
Local auxiliary
64 points (LM0–LM63)
