Ioline 100 - Suggested Settings for Materials

14
Ioline
Material Thickness Blade Offset Force
mils mils grams
Amberlith™/Rubylith™ 1 45
o
15 30-60
Flock 15 Cobra 47 100-200
Thermo-Flock 15 45 15 200-300
Thermo-Film 3 45 15 200-300
Gorilla-Grip 4-5 45 15 200-300
Polyester, Metalized 2 45
o
15 100-140
Reflective, Engineering Grade 5 45
o
15 240-250
Sandblast Mask
2
18
1
- - -
31 Cobra 47 220-260
36 Cobra 47 220-260
40
1
- - -
Stencil, Lacquer Adhering 1 45
o
15 80-100
Stencil, Vinyl 4 45
o
15 200-220
Stencil, Water Soluble 1 45
o
15 125-135
Tag Board 10 45
o
15 300-400
Vinyl, Calendered 3 45
o
15 100-150
Vinyl, Cast2 45
o
15 100-150
1
These sandblasts typically have a backing which is designed for cutting by hand.
2
Use the low force setting on the pinchwheels if using a 80 cm or larger cutter .
Suggested Settings
There are many variables that determine cutter output quality. Ioline recom-
mends using low force and speed settings when making the initial test cuts.
Gradually increase these settings until the best values for the material are
found. Refer to Table 1 below for settings for a variety of material types. Force
values are for starting reference only. These settings may vary due to manu-
facturer, color, age, and temperature of the material.
Table 1. Suggested Settings for Different Material Types.
Speed Acceleration Min. Angle Overcut Down Delay
ips g degrees mils milliseconds
med. 0.1 30
o
0-5 0-50
min. 1 15
o
10 0
min. 1 15 10 0
min. 1 15 10 0
min. 1 15 10 0
max. 1 30
o
10 0
min. 1 30
o
10 0
- - - - -
min. 1 15
o
30 0
min. 1 15
o
30 0
- - - - -
max. 1 30
o
10 0
min. 1 30
o
10 0
med. 1 30
o
10 0
min. 0.1 30
o
10 0
med.-max. 1 30
o
10 0
med.-max. 1 30
o
10 0
NOTE: Settings should be adjusted for cutting small letters or intricate detail,
refer to the Cutting Small Characters section.
