IPC CT5 - MACHINE DIMENSIONS

EN
Transported weight
kg 7 7 7
lbs 15,43
Machine dimensions (X, Y, Z)
mm
X = 604
X1 = 770
Y = 399
Y1 = 1049
Z = 412.5
inches
X = 23.77
X1 = 30.31
Y = 15.7
Y1 = 41.29
Z = 16.24
Packed size (length, width, height)
mm
inches
Sound pressure
LpA
(dB)
63,5
Measurement uncertainty
K
(dB)
3
Vibration level (hand)
HAV
m/sec2
1
Measurement uncertainty, k m/sec2 0,5
Gross weight (GVW): maximum permissible weight with the machine fully loaded and ready for use.
The gross weight of the machine comprises the detergent tank lled with clean water, the dirty water
tank, empty, the largest recommended battery pack and all accessories, namely cables, hoses,
detergents and brushes.
Transported weight. the weight of the machine in transit, which includes batteries and clean water.
Data subject to variation without prior warning.
MACHINE DIMENSIONS
X-Y-Z: See “TECHNICAL SPECIFICATIONS” table
Y1
X1
X
Z
Y
9
