IPC CT5 - TECHNICAL SPECIFICATIONS

EN
TECHNICAL SPECIFICATIONS
B 230 V AC 115 V AC
Brush diameter
mm 280 280 280
inches 11,02
Brush rotation speed
rpm
rpm
160
Brush motor power
W 100
HP 0,134
Maximum brush pressure
g/cm
2
35 35 35
kPa 3,4 3,4 3,4
Suction motor power
W 140
HP 0,187
Solution tank
l 4,8 4,8 4,8
galls. 1,26 1,26 1,26
Dirty water tank
l 5 5 5
galls. 1,32 1,32 1,32
Squeegee width
mm 360-390 360-390 360-390
inches 14.17-15.35 14.17-15.35 14.17-15.35
Rear wheel diameter
mm 200 200 200
inches 7,87 7,87 7,87
Cleaning width
mm 280 280 280
inches 11,02 11,02 11,02
Cleaning capacity per hour
m
2
/h 650
ft
2
/h 6996,5
Maximum slope % 2 2 2
Maximum water and detergent temperature °C 40 40 40
Degree of protection IP IPX3
Power supply voltage at battery charger input Vac 100-240
Power supply frequency at battery charger input Hz 50-60
Current draw at battery charger input A 1,8
Power supply voltage at battery charger output Vcc 42
Maximum scrubber dryer recharge current A 2
Number of batteries no. 1 / /
Battery voltage V 36 / /
Gross weight (GVW)
kg 27 27 27
lbs 59,52
8
