TECHNICAL INFORMATION
General description
This machine is a scrubber dryer for sweeping, washing and drying at, horizontal, smooth or
moderately rough, uniformly structured and obstacle-free oors in civil and industrial premises.
The scrubber dryer spreads a solution of water and detergent in the correct concentration on the
oor and then scrubs it to remove the dirt. By carefully choosing the detergent and brushes (or
abrasive disks) from the wide range of accessories available, the machine can be adapted to a wide
range of combinations of types of oor and dirt.
The machine incorporates a wet vacuuming system which dries the oor immediately after washing.
The drying action is produced by the suction motor, which generates a partial vacuum in the dirty
water tank. Squeegees mounted beneath the tank are designed to collect the lm of dirty water with
the machine moving in both forward and reverse directions.
Parts of the machine
Below is the description of the machine main parts:
• The water/detergent tank (g. 1, ref. 1) contains and carries the mixture of clean water and
cleaning product.
• The dirty water tank (g. 1, ref. 2) collects the dirty water picked up from the oor after washing;
• Control panel (g. 1, ref. 3).
• Head assembly (g. 1, ref. 4), the main element comprises the brush that spreads the detergent
solution over the oor and washes the surface, bringing about the removal of the dirt.
• Front squeegee assembly (g. 1, ref. 5), which wipes and dries the oor when the machine is
pulled toward the operator.
• Rear squeegee assembly (g. 1, ref. 6), which wipes and dries the oor when the machine is
pushed forward by the operator.
• Battery (g. 1, ref. 7).
3
7
Fig.1
2
1
5
4
6
