Controls
The machine has the following controls and indicator lights:
• Main switch (g. 14, ref. 1): connects and disconnects electrical power to and from all functions
of the machine.
• Power on light (mains powered model) (g. x, ref. x): colour yellow, indicates that the power
cable of the machine is connected to the mains supply and the main switch has been depressed
(g. 14, ref. 1).
• Battery charge indicator (battery powered models only) (g. 15, ref. 1): consists of 3 Leds, red,
yellow and green, showing the battery charge level. Possible charge level indications:
• Green Led alight: battery charge > 30.0 %.
• Yellow Led alight: battery charge between 10% and 30%.
• Red Led alight: battery charge between 5% and 10%.
• Red Led blinking: battery charge < 5%, battery completely at; after a few seconds the
brush motor and suction motor will be shut o󰀨;
• Brush control button (g. 15, ref. 2): enables (Led alight) and disables (Led dark) operation
of the “Brush” function; the brush does not start rotating until the “Brush control lever”(g. 15,
ref. 2) is operated.
! INFORMATION
Pressing the brush control button also has the e󰀨ect of automatically enabling the suction
and detergent solution ow functions, which can then be controlled and adjusted by way of
the respective single buttons on the console.
• Suction control button (g. 15, ref. 3): switches on (“Led alight”) and switches o󰀨 (“Led dark”)
the suction motor, which generates the vacuum needed to dry the oor after scrubbing. The
motor comes into operation only when activated by way of the “Brush control lever”.
• Detergent ow button (g.15, ref. 5): enables (Led alight) and disables (Led dark) the ow of
detergent solution, with three levels of delivery available. Flow is enabled only with the brush
in operation.
• ECO button (g.15, ref. 4): enables (Led alight) and disables (Led dark) ECO operating mode.
! INFORMATION
In ECO operating mode, the power of the brush motor and suction motor is reduced
automatically and the ow of detergent solution defaults to delivery level 1.
1
2
1
2
Fig.14 Fig.15
3 45
17
