Cleaning the suction oat
• Release the lid of the dirty water tank.
• Turn the lid over and check that the oats can move freely (g. 29,
ref. 1).
• Clean the seals with a moist cloth (g. 29, ref. 2).
• Ret the lid.
! INFORMATION
Do not clean seals with ethyl alcohol.
Cleaning the water/detergent tank lter
• Remove the dirty water tank and the detergent tank and set them
on the oor, referring to the section “Emptying the water/detergent
tank” and “Emptying the dirty water tank”.
• Remove the lter and wash with water (g. 30, ref. 1).
Cleaning the suction lter
• Remove the dirty water tank from the machine and set it on the
oor, referring to the section “Emptying the dirty water tank”.
• Remove the lter and wash with water (g. 30, ref. 2).
Cleaning the front squeegee suction hose
• Remove the dirty water tank and the detergent tank and set them
on the oor, referring to the section “Emptying the water/detergent
tank” and “Emptying the dirty water tank”.
• Detach the hose from the diverter valve (g. 31, ref. 1) and from the
front squeegee (g. 29, ref. 2).
• Wash the hose by directing water into the bore (g. 32)
• Reattach the hose.
Cleaning the rear squeegee suction hose
• Remove the dirty water tank and the detergent tank and set them
on the oor, referring to the section “Emptying the water/detergent
tank” and “Emptying the dirty water tank”.
• Pull the handle up perpendicular to the machine.
• Lower the squeegee by operating the lever.
• Tilt the machine backwards and rest the handle on the oor.
• Detach the hose from the diverter valve and from the rear squeegee
(g. 33, ref. 1).
• Wash the hose by directing water into the bore (g. 32)
• Reattach the hose.
Fig.29
1
2
1
2
Fig.30
Fig.31
Fig.32
1
2
Fig.33
1
