ipTime IP0416 - Ls;Nat; Load Sharing

User’s Guide
QoS Setup by Port
With Setting QoS by an application port, the upload and download speed of
specified port can be limited at a specified maximum rate or granted at a specified
minimum rate.
External Port Number.
Enter the application port number on WAN side to set QoS.
Protocol
Select the protocol type (TCP / UDP)
Operation Mode
Chose 'Max Rate Limit' or 'Min Rate Grantee'.
Download/Upload
Chose the download and upload speed.
QoS Examples QoS Operations
TCP 80
Max Rate Limit
Download 3Mbps
- The maximum download speed through TCP 80
is limited to 3Mbps
- If other traffic is increase, the TCP 80 download
can be decreased lower than 3Mbps.
TCP 80
Min Rate
Grantee
Upload 2Mbps
- The minimum upload speed through TCP 80 is
granted to 2Mbps
- Even though other traffic is increased
the upload of TCP 80 can be 2Mbps.
6.9 LS/NAT
6.9.1 LOAD SHARING
Click LS/NAT –Load Sharing , refer to the following sketch-up
-71- www.zioncom.net
