User’s Guide
installation of Broadband Router, please backup your installation software and
uninstall your ADSL PPPoE dial-up software by Start->control panel->Add or
Remove Programs.
4.2 INSTALLATION
4.2.1. Setup WAN connection: connect broadband cable (xDSL, Cable Modem
or LAN/ Leased cable) with WAN port of Broadband Router.
4.2.2. Setup LAN connection: connect your computer LAN card’s port or your
switch UPLINK port with one LAN port of Broadband Router by a common network
cable.
Note: All LAN ports of Broadband Router can automatically sense cross cable, so
you can either use through cable or cross cable to connect LAN card or switch.
4.2.3. Turn on the power: connect and the power supply, turn on it. Then
Broadband Router comes to self-detect state. During the self-detect: PWR LED will
be long light, RUN LED will slow flash after correct startup, other four LAN LED and
WAN LED will flash only twice rapidly, then the system will come to normal work
state.
4.2.4. Start computer
LED Description Function
POWER Power Indicator Red for router running
RUN System Status Indicator LED flash when device work normally.
LED doesn’t on or flash refer some problem
with device
LINK/ACT LAN&WAN Status
Indicator
Flashing refers to data transformation
-11- www.zioncom.net
