User’s Guide
configuration on the router.
Primary WAN
All internet traffic not matched any rule will be routed to a Primary WAN.
Auto Line Backup
if any WAN was dead, all traffics will be diverted to another WAN automatically.
WRR Load Sharing
Weight Round Robin (WRR) Load Sharing.
The weight is based on the amount of continuous connections allocated for each
wan.
You assign the weights as a ratio.
User Defined LS
The feature enables to diversify a internet traffic which is defined by user.
The latest rule, the highest priority.
Rule Name
Any string can be entered to distinguish the rules.
Internal PC IP Address
Enter the host IP address that you want to diversity a internet traffic.
Net Mask
Enter the net mask filed to assign a IP subnet range.
(C class)
Net Mask The 4th value in IP address
31 0 ~ 1
30 1 ~ 3
29 1 ~ 7
28 1 ~ 15
27 1 ~ 31
26 1 ~ 63
25 1 ~ 127
24 1 ~ 254
-73- www.zioncom.net
