User’s Guide
Net Mask
The IP address range can be specified by the net mask.
(C class)
Net Mask The 4th value in IP address
31 0 ~ 1
30 1 ~ 3
29 1 ~ 7
28 1 ~ 15
27 1 ~ 31
26 1 ~ 63
25 1 ~ 127
24 1 ~ 254
Protocol
Chose Protocol Type. (any/TCP/UDP)
'Any’ means all protocols. The port number is disable when 'any' is selected.
Destination Port
The port number where the traffic ended.
Accept/Drop
Chose accept or drop for the specified traffics.
Note:
1.Pleaseclike “save”, when you want to keep the configuration in case power
off or reset on the router.
2.It is better to let IP address binding on or use the static IP address on the
client for user self-defined LS.
-82- www.zioncom.net
