Code formulation
2. PACKING AND STORAGE
The original packaging is designed to allow the equipment to be transported and stored without damage,
provided this takes place in dry, ventilated spaces away from heat sources.
Included in the packaging are:
– DOSTEC-AC dosing pump
– Instruction manual
– Oil: AC1/2 250 cm³
AC3 700 cm³
MOTOR
AC1: 0.43 kW 110 V
AC2: 0.43 kW 230 V
AC3: 1.2 kW 230 V
DIAMETER
P24: Ø 24 mm
P34: Ø 34 mm
P49: Ø 49 mm
P61: Ø 61 mm
P77: Ø 77 mm
P95: Ø 95 mm
P110: Ø 110 mm
D69: Ø 69 mm
D95: Ø 95 mm
D115: Ø 115 mm
D142: Ø 142 mm
D163: Ø 163 mm
CYLINDER-PISTON
P: PP – PEUAPM
C: PP – Ceramic
I: AISI316 – Ceramic
F: PVDF – Ceramic
T: PTFE – Ceramic
VALVE-BALL
P: PP – Soda
B: PP – Boron
I: AISI316 – AISI316
F: PVDF – Boron
T: PTFE – Boron
CONNECTION
L:
6 x 12 (6 x 8 PVDF)
M:
¾"
X: 1 - ¼
Y: 1 - ¼" NTP
HEAD
P: Piston
D:Diaphragm
FREQUENCY
1: 26 strokes/min
2: 43 strokes/min
3: 72 strokes/min
4: 144 strokes/min
STROKE
1:4.5 mm
2: 7.5 mm
3: 9 mm
4: 15 mm
73 - AC2 P 4 4 - P61 P B M
