ITech IT6522D User Manual

Specification
Copyright ©ITECH Electronics Co., Ltd. 42
Chapter5 Specification
This chapter will introduce the rated voltage, current, power and many other main
parameters of IT6500D series.
5.1 Main technical parameters
Parameter
IT6512D Version: V1.4
Output Rating
( 0
℃
-40
℃
)
Output Voltage
0-80V
Output Current
0-120A
Output Power
0-1800W
Line regulation
±(%of Output+Offset)
Voltage
≤0.01%+10mV
Current
≤0.01%+60mA
Load regulation
±(%of Output+Offset)
Voltage
≤0.01%+30mV
Current
≤0.05%+120mA
Setup Resolution
Voltage 10mV
Current
10mA
Power
0.1W
Read Back Resolution
Voltage
10mV
Current
10mA
Power 0.1W
Setup Accuracy
1
( within 12 months, 25
℃
±5
℃
)
±
(%of Output+Offset)
Voltage ≤0.05%+30mV
Current ≤0.2%+120mA
Power 1%+30W
Read Back Accuracy
2
( within 12 months, 25
℃
±5
℃
)
±(%of Output+Offset)
Voltage ≤0.05%+30mV
Current ≤0.2%+120mA
Power 1%+30W
Ripple
(20Hz -20MHz)
Voltage ≤80mVp-p
Current ≤0.05%+60mArms
Setup Temperature
Coefficient
(%of Output/
℃
+Offset)
Voltage ≤0.01%+30mV
Current ≤0.02%+120mA
Read Back Temperature
Coefficient
(%of Output/℃ +Offset)
Voltage ≤0.01%+30mV
Current ≤0.02%+120mA
Rise time( no load ) Voltage ≤30ms
Rise time( full load ) Voltage ≤30ms
Fall time( no load )
Voltage
≤200ms
Fall time( full load )
Voltage
≤40ms
Transient Response
Time
Voltage ≤3ms
AC Input
3
Voltage
220Vac±10%
Frequency
47Hz-63Hz
Setup stability-30min
( %of Output +Offset )
Voltage
≤0.05%+30mV
Current ≤0.1%+120mA
Setup stability-8h
( %of Output +Offset )
Voltage
≤0.05%+30mV
Current
≤0.1%+120mA
Readback
stability-30min
( %of Output +Offset )
Voltage
≤0.05%+30mV
Current ≤0.1%+120mA
Readback stability-8h
( %of Output +Offset )
Voltage
≤0.05%+30mV
Current
≤0.1%+120mA
