Operation Manual – ITW GSE 7400 Battery Powered GPU
90 kVA
Operator’s Instructions
Document No. 575.410DB Page 71 of 195
Setup – Menu Structure (Continued)
11:27:47 Setup Menu 24/09/2019
28V Compensation
28V Current Limit Step Size
28V Interlock
Fan Test
Customer ID
Menu Lock
 Back  Select Parameter.
11:27:47 Setup Menu 24/09/2019
Fan Test
Disabled
 Back  Modify
Settings:
Enabled
Disabled
Bypassed
11:27:47 Setup Menu 24/09/2019
28V EF Interlock
 Back  Modify
Settings:
50 / 100 / 200 / 300 A
11:27:47 Setup Menu 24/09/2019
Current Limit Step Size
300A
 Back  Modify
11:27:47 Setup Menu 24/09/2019
28V Compensation
0.0V/600A
 Back  Modify
Settings:
0 – 3.0 V
Settings:
Enabled
Disabled
11:27:47 Setup Menu 01/01/2017
<UNDEFINED>
 Back  Modify
6 Characters:
A – Z , 0 – 9 , Space -
11:27:47 Setup Menu 24/09/2019
Menu Lock
Disabled
 Back  Modify
Settings:
Enabled
Disabled
