The interface of the control software is showed as below:
Please set the parameters of COM number, baud rate, data bit, stop bit and the
parity bit correctly, only then will you be able to send command in Command
Sending Area.
Baud rate: 9600
Data bit: 8
Stop bit: 1
Parity bit: none
RS232 CONTROL
Monitoring area, indicates whether the
command sent works.
Command sending area
Parameter Configuration area
13
