J-TECH JTECH-4K88-EX-RX User Manual

4K HDBaseT Matrix Switcher
Video Input
Input
8 HDMI
Input Connector
Female HDMI
Input Level
T.M.D.S. 2.9V~3.3V
Input Impedance
100Ω (Differential)
HDMI Standard
Support 4K@60 4:2:0 & HDCP2.2
Video Output
Output
1 HDMI; 7 HDBaseT
Output Connector
Female HDMI; Female RJ45(with LED indicators)
Output Level
T.M.D.S. 2.9V~3.3V
Output Impedance
100Ω (Differential)
HDMI Standard
Support 4K@60 4:2:0 & HDCP1.4
Video general
Video Signal
HDMI (or DVI-D)
Transmission Distance
1080P@60Hz ≤70m; 4Kx2K@60Hz ≤40m
Resolution Range
Up to 4Kx2K@60Hz
EDID Management
In-built EDID data and manual EDID management
Gain
0 dB
Bandwidth
10.2Gbit/s
Switching Speed
200ns (Max.)
Audio general
Output Signal
Stereo audio; Digital audio
Analog Audio Output
Support PCM
Digital Audio Output
Supports PCM, Dolby, DTS, DTS-HD
Frequency Response
20Hz~20KHz
Output Connector
1 L&R(RCA); 1 SPDIF
Control Parts
Control Ports
8 IR OUT; 1 IR ALL OUT; 7 IR IN; 1 IR EYE;
1 TCP/IP; 1 RS232
Panel Control
Front panel buttons
RS232 Control
3-pin pluggable terminal block
IR
Extended IR receiver
TCP/IP Control
Web-based GUI
General
Power Supply
AC100-240V~, 50/60Hz
Power Consumption
93W (Max)
Operating Temperature
0 ~ +50℃
Relative Humidity
10% ~ 90%
Dimension (W*H*D)
436.4mm x 44.0mm x 300.0 mm
Net weight
2.9Kg
SPECIFICATION
32

J-TECH JTECH-4K88-EX-RX Specifications

General

Brand	J-TECH
Model	JTECH-4K88-EX-RX
Category	Switch
Language	English
