J2 225 System Manual
Version 1.0 May 29, 2012
+12VDV Power Out
The J2 225 has a fused power out connector that supplies a total of 12VDC, up to 2amp.
The power supply connector is a standard notebook locking type that plugs into the
system power input connector, located in the cable well, seen below
Power Input connector
Typical Power Consumption J2 225
The typical power consumption of the J2 225 is lower than a notebook computer and more
comparable to a netbook computer. Using the latest generation Intel’s Atom processor and
chipset allows for much lower power consumption than previous generations of POS computers.
When coupled with the proper system configuration, this can greatly reduce the system total
carbon foot print.
Test conditions
Voltage: 220VAC 50Hz, measured voltage 236 VAC
OS: POSReady 7
Heavy Load Program: PassMark BurnInTest defaults values
Maximum load: PassMark BurnInTest Max CPU Temp
Temperature: 26c
All systems are tested in their standard hard drive configuration. Results are +/- 15%.
J2 225 D2550 1.86GHz
1: Normal application including most POS software 23 watts
2: Very heavy load application 26 watts
3: Maximum load 29 watts
4: Normal POS app, backlight dimmed 20 watts
4: Normal POS app, backlight off 18 watts
5: Standby, unit off, waiting for wake on LAN, RTC or power button >4 watts
