Jackle ProPuls 320 Compact - Control Elements and Operation; Control Panel Layout and Components

ProPuls 320C
Operating manual Page 39
16. Control elements
Brenner
Zentralanschluss
Central
torch connection
Hauptschalter
(Rückseite)
Main switch
(Back side)
Massebuchse
Workpiece socket
TEST
ProPuls
A
V
HOLD
F X
+ Buchse Elektrode / WIG
+ socket MMA / TIG
Steuerbox ProPuls
Control unit ProPuls
Anschluss up/down Brenner
Connection up/down torch
Wasservorlauf ‘blau-kalt’ DN 5
water flow ‘blue-cold’ DN 5
Wasserrücklauf ‘rot-heiß’ DN 5
water runback ‘red-hot’ DN 5
Kühlgerät
Cooling unit
TEST
ProPuls
A
V
HOLD
F X
Picture 16.1 Control elements
