Jackson AJX Series User Manual

RINSE
HEATER
MODEL
VOLTS
PH HZ RATINGS AMPS
CIRCUIT
AJX-54CE 208 1 60 N/A 96.8 A 125 AMP
AJX-54CE 230 1 60 N/A 88.6 A 125 AMP
AJX-54CE 208 3 60 N/A 56.7 A 80 AMP
AJX-54CE 230 3 60 N/A 51.9 A 70 AMP
AJX-54CE 460 3 60 N/A 26.0 A 35 AMP
AJX-54CS 208 1 60 N/A 10.3 A 15 AMP
AJX-54CS 230 1 60 N/A 10.3 A 15 AMP
AJX-54CS 208 3 60 N/A 6.7 A 15 AMP
AJX-54CS 230 3 60 N/A 6.7 A 15 AMP
AJX-54CS 460 3 60 N/A 3.4 A 15 AMP
AJX-76CE 208 1 60 N/A 102.8 A 150 AMP
AJX-76CE 230 1 60 N/A 94.6 A 125 AMP
AJX-76CE 208 3 60 N/A 60.1 A 80 AMP
AJX-76CE 230 3 60 N/A 55.3 A 70 AMP
AJX-76CE 460 3 60 N/A 27.7 A 35 AMP
AJX-76CS 208 1 60 N/A 16.3 A 25 AMP
AJX-76CS 230 1 60 N/A 16.3 A 25 AMP
AJX-76CS 208 3 60 N/A 10.1 A 15 AMP
AJX-76CS 230 3 60 N/A 10.1 A 15 AMP
AJX-76CS 460 3 60 N/A 5.1 A 15 AMP
AJX-90CE 208 1 60 N/A 105.3 A 150 AMP
AJX-90CE 230 1 60 N/A 97.1 A 125 AMP
AJX-90CE 208 3 60 N/A 62.3 A 80 AMP
AJX-90CE 230 3 60 N/A 57.5 A 80 AMP
AJX-90CE 460 3 60 N/A 28.8 A 40 AMP
AJX-90CS 208 1 60 N/A 18.8 A 25 AMP
AJX-90CS 230 1 60 N/A 18.8 A 25 AMP
AJX-90CS 208 3 60 N/A 12.3 A 20 AMP
AJX-90CS 230 3 60 N/A 12.3 A 20 AMP
AJX-90CS 460 3 60 N/A 6.2 A 15 AMP
AMPS CIRCUIT
82.4 A 125 AMP
75.5 A 100 AMP
48.4 A 60 AMP
44.4 A 60 AMP
22.3 A 30 AMP
10.3 A 15 AMP
10.3 A 15 AMP
6.7 A 15 AMP
6.7 A 15 AMP
3.4 A 15 AMP
88.4 A 125 AMP
81.5 A 125 AMP
51.8 A 70 AMP
47.8 A 60 AMP
24.0 A 30 AMP
16.3 A 25 AMP
16.37 A 25 AMP
10.1 A 15 AMP
10.1 A 15 AMP
5.1 A 15 AMP
90.9 A 125 AMP
84.0 A 125 AMP
54.0 A 70 AMP
50.0 A 70 AMP
25.0 A 30 AMP
18.8 A 25 AMP
18.8 A 25 AMP
12.3 A 20 AMP
12.3 A 20 AMP
6.2 A 15 AMP
With 18kW Wash
Tank Heater
With 15kW Wash
Tank Heater
AJ-44T Series Technical Manual 7610-003-07-21
Issued: 03-21-2006 Revised: 01-30-2009
SECTION 1: SPECIFICATION INFORMATION
ELECTRICAL REQUIREMENTS (CONTINUED)
4
