Jackson AJX Series - Incoming Plumbing Assembly

AJX-44 & AJX-54 Series Technical Manual 7610-003-60-98
Issued: 01-19-2009 Revised: 01-30-2009
SECTION 5: PARTS SECTION
INCOMING RINSE PLUMBING ASSEMBLY
49
1
22
2
3
3
4
4
5
6
6
7
8
9
9
26
10
5
5
12
13
25
15
16
14
17
5
18
7, 4
20
23
28
22
21
27
7
11
24
24
19
4
4
7
Tube Length Chart
Item #
Length (Inches)
8 1/2” x 2”
10 1/2” x 3.06”
11 1/2” x 2.08”
12 1/2” x 4”
13 1/2” x 5.27”
17 1/2” x 4.185”
19 1/2” x 5.92”
25 1/2” x 5.75”
26 1/2” x 4.75”
27 1/2” x 40” (High Hood)
27 1/2” x 33” (Low Hood)
