SECTION 5: PARTS SECTION
VENT COWL ASSEMBLY/VENT SCOOP OPTION
78
Vent Cowl Cover Weldment
05700-011-74-67
Gasket, Top Vent Cowl
05330-031-83-47
Vent Cowl Weldment
(High Hood)
05700-041-86-94
Gasket, Side Vent Cowl
05330-031-83-48
Locknut, 1/4”-20 Hex with Nylon Insert
4 per
05310-374-01-00
VENT SCOOP OPTION
Vent Scoop Assembly
05700-002-04-08
Vent Cowl Weldment
(Low Hood)
05700-002-13-12
