AJX-44 & AJX-54 Series Technical Manual 7610-003-60-98
Issued: 01-19-2009 Revised: 01-30-2009
SECTION 1: SPECIFICATION INFORMATION
OPERATING CHARACTERISTICS
2
RACKS PER HOUR:
AJX-44, 66, 80, 54, 76, 90 (High Temp) 225
AJX-44, 66, 80, 54, 76, 90 (Low Temp) 209
DISHES OR GLASSES PER HOUR:
AJX-44, 66, 80, 54, 76, 90 (High Temp) 5625
AJX-44, 66, 80, 54, 76, 90 (Low Temp) 5225
PREWASH TANK CAPACITY (GALLONS):
AJX-66, 76 17.25
AJX-80, 90 17.25
WASH TANK CAPACITY (GALLONS):
AJX-44, 66, 80, 54, 76, 90 20.4
PREWASH PUMP CAPACITY (GPM):
AJX-66, 76 120
AJX-80, 90 270
WASH PUMP CAPACITY
GALLONS PER MINUTE (ALL MODELS): 270
VENTING REQUIREMENTS (CFM)(100% CAP.):
INPUT END 200
OUTPUT END 400
TOTAL 600
CONVEYOR SPEED (FPM):
AJX-44, 66, 80, 54, 76, 90 (High Temp) 6.2
AJX-44, 66, 80, 54, 76, 90 (Low Temp) 5.75
GALLONS PER RACK:
AJX-44, 66, 80, 54, 76, 90 (High Temp) .69
AJX-44, 66, 80, 54, 76, 90 (Low Temp) .79
WATER TEMPERATURES:
AJX-44, 66, 80, 54, 76, 90 MODELS:
PREWASH (RECOMMENDED)(AJX-66,76,80,90) 110-140F
WASH (MINIMUM) 160F
RINSE (MINIMUM) 180F
FLOW PRESSURE (PSI) 15
FLOWRATE (GPM):
AJX-44, 66, 80, 54, 76, 90 (High Temp) 2.57
AJX-44, 66, 80, 54, 76, 90 (Low Temp) 2.74
STEAM COIL TANK HEAT (TS MODELS ONLY):
STEAM INLET PRESSURE (PSIG) 10-20
STEAM CONNECTION NPT 3/4”
CONSUMPTION @ 15 PSIG (lbs/hr): 60
MOTOR ELECTRICAL CHARACTERISTICS:
DRIVE MOTOR HP 1/4
WASH MOTOR HP 2
PREWASH MOTOR HP:
AJX-66CE/CS & AJX-76CE/CS MODELS 1
AJX-80CE/CS & AJX-90CE/CS MODELS 2
NOTE: Always refer to the machine data plate for specific
electrical and water requirements. The material provided
on this page is for reference only and may be subject to
change without notice.
