2) ● key Decimal point; toggles between upper limit and lower limit setting when HI-LO-OK
function is enabled. (See 7-2-1)
1) PRINT key Outputs data when Prt.Pr (print stably) is selected as the print mode.
2) ZERO key Zeros the display (within 2% of max.capacity) or cancels Tare action.
3) TARE key Inputs the weight of the object on the weighing pan as a Tare value; inputs
the indicated value entered via the numeric keys as a pre-set Tare value; cancel tare
action.
4) CE key Clears the indicated input values.
5) MC/CK key Short press deletes accumulation records; long press to initial Upper &
Lower Quantity Limit setting.
6) MR key Recalls and displays the total Accumulation data (weight, total count and
number of weightments ) and the first 10 records in details.
7) UWS key Inputs the indicated unit weight value entered via numeric keys
8) M+ key Adds the indicated weight or piece count value into Accumulation memory.
9) SMPL key Short press enters the sampling mode.
4-3 Power Supply
Power supply
Please verify the local AC power source and switch the two-stage switch to the proper place
before plugging into the power outlet.
Alternative power supply
1) AC 110V/220V (AC±10%)
2) (6V/4A) internal rechargeable battery
Power Consumption
About 300mW (without backlight)
About 380 mW (with backlight)
Low battery warning
When ― ‖ appears in the upper left corner of the weight window, the battery power
requires recharging. The charge lamp turns green from red when the recharging is completed
(which takes about 8 hours). Disconnect the scale from power supply when it is fully charged.
A full charged battery can operate the scale for approximately 65 hrs with backlight, 80hrs
without backlight.
Note: Battery is to replaced only by an authorized service dealer .Risk of explosion can occur
if replaced with the wrong type or connected improperly
