Tecnnical Data and Specifications 8-0
Revision 2 - 20 March, 1997 HP SERIES DIMMER OPERATING MANUAL
8.0 Technical Data and Specifications
PARAMETER HP12-TR HP12-SC HP12-WMTR HP12-WMSC
No. of Channels: 12
Input Power
Requirements:
3 Phases plus Neutral and Earth
220-240 volts phase-to-neutral
380-415 Volts AC Phase-Phase +/-10%
40 Amps / Phase
Full size (min 40A) Neutral conductor
Max upstream protection 50A per phase
Load Power per chan: 20VA - 2.5kVA 5VA - 2.5kVA 20VA - 2.5kVA 5VA - 2.5kVA
Max Dissipation: <24W/chan
(<300W total)
<35W/chan
(<500W total)
<24W/chan
(<300W total)
<35W/chan
(<500W total)
Max Ambient Temp: 45ºC
Control Signal: DMX-512 (1990) Protocol
DMX Connectors: AXR-5-21B,
AXR-5-22B
AXR-5-21B,
AXR-5-22B
Six-way screw
terminal block
Six-way screw
terminal block
Test Function Level: 0 to Full with detent each step
LED Indicators: Status, Control and Output mimics; DMX; Phases A, B & C
Output Protection: 12 x 11.5 amp circuit breakers
Overvoltage Limit 300V +/-10%
Undervoltage Limit 180V+/-10%
Neutral - Earth Voltage
Limit
15V+/-10%
Cooling System 1 x 80mm speed
controlled fan
2 x 80mm speed
controlled fans
1 x 80mm speed
controlled fan, aided
by convection
2 x 80mm speed
controlled fans,
aided by convection
Gate Firing System Opto-Isolator
Continuous DC gate
firing
Opto-Isolator
Continuous DC gate
firing
Control Devices 12 x 40A Triac 24 x 35A SCR 12 x 40A Triac 24 x 35A SCR
Output risetime @ 50%
dim
(10% - 90%, 2500W
incandescent load)
280 µsec +/-10% 500 µsec +/-10% 280 µsec +/-10% 500 µsec +/-10%
Power Supply Entry:
2 metre tail with
Clipsal 56P532 plug
2 metre tail with
Clipsal 56P532 plug
Internal terminal
block
Internal terminal
block
Output Connectors:
(Australia)
1 x 10 amp Clipsal
415 per channel
1 x 10 amp Clipsal
415 per channel
Internal terminal
blocks
Internal terminal
blocks
