Dimmer Operation 4-7
Revision 2 - 20 March, 1997 HP SERIES DIMMER OPERATING MANUAL
4.1.7.2 Scene
E Figure 4.3
Once a Scene (“SC1” or “SC2”) is selected, the display will scroll the message:
“PRESS SELECT AND HOLD WHILE CHANGE LEVEL FOR EACH
CHAN”.
• For each channel required to Build the Scene, press and hold the SELECT
button.
• The display will initially show the last recorded level for that channel, which
may then be changed by rotating the LEVEL/FUNCTION encoder wheel.
• Once all the required channels have been changed, press ENTER to confirm
the changes.
• The display will change to “OK” to indicate the dimmer is now in normal
operating mode.
4.1.8 RUN menu
E Figure 4.4
The HP12-TR / HP12-SC dimmers offer a range of pre-recorded Snapshots, Scenes
and Chases that may be used for testing purposes or for when the dimmer rack is
used in stand-alone (no control desk) applications.
The Snapshots and Scenes must be recorded via the Build menu (see section 4.1.7).
The Chase patterns are factory-set and cannot be changed. The output levels of
Snapshots and Scenes may be varied with the LEVEL/FUNCTION encoder wheel,
which becomes a master level control. During chases the encoder wheel becomes a
chase rate control.
In all cases, individual channel levels may be changed. Once changed, however, they
remain at the new level regardless of the setting of the master level control.
Note that any previously disabled channels will remain disabled when in RUN
mode, with chase sequences abbreviated to avoid visible gaps.
• To run a Snapshot, Scene or Chase, press the RUN keypad button.
• Select either a Snapshot (“SP1”, “SP2”, or “SP3”), a Scene (“SC1” or
“SC2”), or a Factory Preset Chase (“PR1”, “PR2”, “PR3”, “PR4”, “PR5”,
or “PR6”) with the FUNCTION encoder wheel.
• Press ENTER to confirm the selection.
4.1.8.1 Snapshot
E Figure 4.4
If Snapshot 2 (“SP2”) is selected, the display will scroll with the message “SP2
ON LEVEL 100”.
• The output level may be altered with the LEVEL/FUNCTION encoder
wheel and the display will indicate a level between 100% and 0%.
• Pressing a channel SELECT button will isolate that channel from the master
level control. The STATUS LED will flash to show the channel is isolated.
Pressing the SELECT button again will re-connect the channel to the master
level control.
