Tecnnical Data and Specifications 8-5
Revision 2 - 20 March, 1997 HP SERIES DIMMER OPERATING MANUAL
8.2 DMX connector pin-outs
PIN
No
CONNECTION
(DMX IN)
CONNECTION
(LOOP)
1 NC SHIELD
2 IN- OUT-
3 IN+ OUT+
4 Loop thru + Loop thru +
5 Loop thru - Loop thru -
8.3 DMX bank allocations
BANK
CHANNELS
BANK
CHANNELS
1 1 - 12 23 265 - 276
2 13 - 24 24 277 - 288
3 25 - 36 25 289 - 300
4 37 - 48 26 301 - 312
5 49 - 60 27 313 - 324
6 61 - 72 28 325 - 336
7 73 - 84 29 337 - 348
8 85 - 96 30 349 - 360
9 97 - 108 31 361 - 372
10 109 - 120 32 373 - 384
11 121 - 132 33 385 - 396
12 133 - 144 34 397 - 408
13 145 - 156 35 409 - 420
14 157 - 168 36 421 - 432
15 169 - 180 37 433 - 444
16 181 - 192 38 445 - 456
17 193 - 204 39 457 - 468
18 205 - 216 40 469 - 480
19 217 - 228 41 481 - 492
20 229 - 240 42 493 - 504
21 241 - 252 43 505 - 512
22 253 - 264
8.4
