rate control once more. There is no master level control for this function.
The factory Preset Chase patterns for HP12-TR [HP6] are as follows:
PR1 Channels 1 to 12 in sequence (12 step chase)
PR2 Channels 12 to 1 in sequence (12 step reverse chase)
PR3 Channels 1 to 12 in sequence (12 step shadow chase) ie. chase channel off
PR4 12 Channel Random chase
PR5 Channels 1 & 2 crossfade to Channels 3 & 4.....(6 step 2-channel x-fade)
PR6 Channels 1, 2, 3 crossfade to Channels 4, 5, 6....(4 step 3-channel x-fade)
4.1.9 TEST function
E Figure 4.2
Each channel may be tested individually, or as a group, by fading them from 0 to
100%. Any previously disabled channel may be selected and tested.
• Press the TEST keypad button and the display will show “TEST”.
• Next press the desired channel SELECT buttons. This will take the selected
channel(s) off-line from the DMX input. The remaining channel(s) will stay
on-line.
• The STATUS LED(s) will flash to indicate which channel(s) are under test. As
the LEVEL/FUNCTION encoder wheel is rotated, the channel level(s) will
change from their current level.
• When all tests are completed, press the NORMAL button. The display will
change to “OK” to indicate the dimmer is now back in normal operating mode
and all channels are once again on-line to the DMX input control signal.
4.2 Deep clear
E Figure 4.2
In the event of a software “lockup” or error message (see section 5.2), the HP dimmers
have a facility that enables them to be Deep Cleared.
CAUTION
THIS FUNCTION WILL ERASE THE CURRENT SETTINGS IN MEMORY
AND REQUIRES RE-INITIALISING OF THE OUTPUT VOLTAGE AND
NUMBER OF CHANNELS. ENSURE THAT THE VOLTAGE IS SET TO
120 VOLTS IF RUNNING ANY 120 VOLT LAMPS, OR DAMAGE TO THE
LAMPS MAY RESULT.
• Hold down the MODE and DMX BANK buttons while turning power ON to the
dimmer.
• Use the FUNCTION encoder wheel to select either “120V” output or “240V”
output on the display and press ENTER. Individual channel output voltage may be
changed later via the MODE menu (see section 4.1.4.1).
• Next use the encoder wheel to select “12ch” output (for HP12-TR / HP12-SC),
