Page 12
Figure 6. Two Heat Pump Plumbing Layout
Figure 7. Four Heat Pump Plumbing Layout
Manual Bypass Valve
2” PVC
3” PVC
Optional
Isolation Valves
From Filter
To Pool
Manual Bypass Valve
Optional
Isolation Valves
From Filter
To Pool
2” PVC
3” PVC
