Page 29
Key
No. Description Model No.
Order
Part No.
1 Top Enclosure, Jacket 1500 R3009700
1 Top Enclosure, Jacket 2000, 2500, 3000 R3009100
2 Service Access Panel All R3000500
3 Control Cover - Smoked All R3000601
4 Fan Motor, 1/6 HP, 208 - 230 VAC 1500 R3000703
4 Fan Motor, 1/2 HP, 208 - 230 VAC 2000, 2500, 3000 R3000701
5 Contactor, 1-Phase All R3000801
5 Contactor, 3-Phase 2000, 2500, 3000 R3000802
6 Transformer, 240V 24VA All R3000901
7 Water Pressure Switch All R3001000
8 Capacitor, Fan Motor, 3/370 MFD 1500 R3001101
8 Capacitor, Fan Motor, 7.5/370 MFD 2000, 2500, 3000 R3001100
9 Capacitor, Compressor, 60/370 1500 R3001204
9 Capacitor, Compressor, 80/370 2000, 2500, 3000 R3001203
10 Controller Assembly, Universal All R3008800
11 Refrigerant HP Switch All R3001400
12 Refrigerant LP Switch All R3001500
12 Refrigerant LP Switch (Heat/Cool) 2500,3000 R3001501
13 Wire Harness Kit (Not Shown) All R3009000
14 Fan Blade Set 1500 R3001701
14 Fan Blade Set 2000, 2500, 3000 R3001700
15 Fan Guard 1500 R3001801
15 Fan Guard 2000, 2500, 3000 R3001800
16 Plumbing Bypass Assembly All R3001900
17 2” PVC Union Set All R3002000
18 Evaporator Coil/Guard 1500 R3002104
18 Evaporator Coil/Guard 2000 R3002101
18 Evaporator Coil/Guard 2500 R3002102
18 Evaporator Coil/Guard 3000 R3002103
19 Heat Exchanger Drain Kit (Not Shown) All R3002200
20 Heat Exchanger Replacement Kit 1500 R3009900
20 Heat Exchanger Replacement Kit 2000, 2500, 3000 R3002300
21 Compressor (40K), 1-Phase 1500 R3009800
21 Compressor (60K), 1-Phase 2000 R3002500
21 Compressor (68K), 1-Phase 2500 R3002600
21 Compressor (81K), 1-Phase 3000 R3002700
21 Compressor (60K), 3-Phase 2000 R3003400
21 Compressor (68K), 3-Phase 2500 R3003500
21 Compressor (81K), 3-Phase 3000 R3003600
22 Thermal Expansion Valve, 2 1/2 Ton (Not Shown) 1500 R3002803
22 Thermal Expansion Valve, 5 Ton (Not Shown) 2000, 2500, 3000 R3002801
23 Water Temperature Sensor All R3002900
24 3-Phase Monitor (3-Phase Models Only) (Not Shown) 2000, 2500, 3000 R3003000
25 Air Temperature Sensor All R3003100
26 Reversing Valve (Optional, Not Shown) 2500,3000 R3003800
27 Achor Bracket Set (Not Shown) All R3003203
28
29
Heat Pump Drain Kit (Not Shown)
Junction Box Cover
All
All
R3004100
R3004600
30 Power Interface PCB All R3009200
31 Fan Relay (Not Shown) All R3009300
9.1 Ordering Information
To order or purchase parts for the AE-Ti models
of heat pumps, contact your nearest Jandy dealer or
distributor. See the Jandy web site at www.jandy.com
Section 9. Replacement Parts
for the nearest service center. If they cannot supply you
with what you need, contact Jandy Customer Service
Department at P.O. Box 6000, Petaluma, California,
94954, Telephone (707) 776-8200 extension 245.
9.2 Jandy AE-Ti Heat Pumps Parts List
