Page 7
ATTENTION
Lorsque l’équipement d’une piscine est situé
sous la surface de l’eau, une fuite provenant de
n’importe quel élément peut causer une perte
d’eau importante ou une inondation. Jandy Pool
Products, Inc. n’est pas responsable des pertes
d’eau, des inondations ou des avaries causées
par une installation ou un entretien inadéquat.
PRECAUCIÓN
Cuando el equipo de la piscina esté situado
por debajo de la superfi cie de la piscina, la
fuga de cualquiera de los componentes, podría
ocasionar la pérdida de grandes cantidades de
agua o inundación. Jandy Pool Products, Inc. no
se responsabilizará de dichas pérdidas de agua
o inundaciones, ni de los daños que puedan
derivarse de las mismas.
Avoid placing the heat pump in locations where
it can cause damage by water or condensate leakage. If
this is not possible, provide a suitable drain pan to catch
and divert any leakage.
All criteria given in the following sections reflect
minimum clearances. However, each installation must
also be evaluated, taking into account the prevailing
local conditions such as proximity and height of walls,
and proximity to public access areas.
2.2.2 Clearances
The heat pump must be placed to provide
clearances on all sides for maintenance and inspection.
See Table 2.
24” (60 cm) access in front of the heat pump
provides adequate room for serviceability.
If the heat pump is to be installed in a garage
or under a vertical overhang, the unit must have a
minimum of 5 feet clearance from the top of the heat
pump.
In the U.S., the heat pump must be installed at least
5 feet (1,5 meters) from the inside wall of the pool or spa
unless the heat pump is separated from the pool or spa by
a 5 foot high solid fence or other permanent barrier.
Section 2. Installation Instructions
2.1 General Information
Install the Jandy heat pumps in accordance
with the procedures in this manual, local codes and
ordinances, and in accordance with the latest edition of
the appropriate national code. (See Section 1.4, “Codes
and Standards”.)
Correct installation is required to assure safe
operation. The requirements for Jandy heat pumps
include the following:
1. Field assembly (if required).
2. Appropriate site location and clearances.
3. Suffi cient air ventilation.
4. Proper electrical wiring.
5. Adequate water fl ow.
This manual provides the information needed to
meet these requirements. Review all application and
installation procedures completely before continuing the
installation.
2.2 Location Requirements
2.2.1 Introduction
NOTE Indoor installations require special
considerations for condensate drainage and
venting the cold air produced by the heat
pump. Contact the Jandy Heat Pump Technical
Service Department at (954) 970-4800.
CAUTION
When pool equipment is located below the pool
surface, a leak from any component can cause
large scale water loss or fl ooding. Jandy Pool
Products, Inc. cannot be responsible for such
water loss or fl ooding or resulting damage.
Side of Heat
pump
Minimum Clearances for
Operation
Recommended Clearances
for Serviceability
Inches Centimeters Inches Centimeters
Front
6152460
Rear
6151230
Left
6151230
Right
6151230
Top
60 150 60 150
NOTE Clearances listed in
Table 2 are manufacturer’s
tested values. These are
given as minimum values.
Where local and national
codes apply, and values are
different than those listed in
Table 2, use the greater value
to ensure safe and proper
operation.
Table 2. Heat Pump Clearances
