Page 9
Figure 7 . S weep E lb ow
N ote: Do not
ov ertighten.
LX i H e a t e r
CV F i l t e r
S H P
P u m p
S w e e p E l b o w
P / N S E A Q L1001
S w e e p E l b o w
P / N S E F L1002
7 ½ ”
M i n i m u m
Figure 8 . LX i Heater, C V Filter and S HP Pump S weep E lb ow I nstallation
C artridge Pool Filters - C L and C V S eries Filters
b. Be sure there is a minimum distance of
7½ inches between the center of the pump
accommodate the sweep elbow(s). See
Figure 8 for recommended installation
N O T E T h e S H P p u m p sh o w n i n F i g u r e 8 i s f o r r e f e r e n ce
o n l y . T h e Ja n d y sw e e p e l b o w a l so w o r ks w i t h t h e
M H P a n d P H P se r i e s p u m p s.
NOTE Besuretouse2"or2½"schedule40PVCpipe.
c. Clean the cut ends of the pipe and both ends
of the sweep elbow(s) with an appropriate
NSF
®
Glue the sweep elbow(s) onto the cut pipe
ends using an appropriate All Purpose NSF
®
NOTE: JandyrecommendsWeld-On724PVCtoCPVC
CementtoglueSchedule40PVC.
d. After the glue is cured, close the pressure
6. Make all plumbing connections in accordance
with local plumbing and building codes. Filter
connections are provided with an o-ring seal. To
avoid damage to the o-rings, use only a silicone
base lubricant on the o-rings. Do not use pipe joint
compound, glue or solvent on inlet/outlet union
coupling nuts.
7. Keep piping tight and free of leaks. Pump suction
tank or loss of prime at the pump. Pump discharge
line leaks may show up as dampness or jets of
water.
9. Connect the pipes using the unions supplied with
Do not use Teon tape or pipe dope on
any unions. Assemble the unions dry and hand
tighten. See Figure 6.
using a Jandy universal union. The plumbing must
contain a ball valve as shown in Figure 6.
C A U T I O N
B e su r e t h a t a l l p r o vi si o n s f o r w a st e w a t e r d i sp o sa l
m e e t l o ca l , st a t e o r n a t i o n a l co d e s. D u r i n g a n y
d r a i n i n g p r o ce ss, o n e h u n d r e d g a l l o n s ( 100 g a l s. )
o r m o r e o f p o o l w a t e r w i l l b e d i sch a r g e d . CL a n d CV
( Ca r t r i d g e ) F i l t e r s a r e n o t su b j e ct t o b a ckw a sh i n g . D o
n o t d i sch a r g e w a t e r w h e r e i t w i l l ca u se f l o o d i n g o r
d a m a g e .
