Reactive Power Controller
= Key 1 = Key 2 = Key 3
Table Modbus
Description Address r/w Format Unit Comment
Current 1000 r word mA
Voltage L-L 1002 r word V Urated +10% -15%
Reactive power 1004 r word Var + = cap, - = ind
Cos(phi) 1006 r word + = cap, - = ind
Outputs 1008 r word Bit 0 K1 (1=On, 0=Off)
Bit 1 K2
Bit 2 K3
.. ..
Bit 11 K12
Bit 12 Alarm output
Alarm calls 1010 r word Bit 0 Low voltage
Bit 1 Overvoltage
Bit 2 Current too low
Bit 3 Current too high
Bit 4 Insufficient capacitor power
Bit 5 Supply of real power
Bit 6 Harmonic limits exceeded
Bit 7 Overtemperature
Switchings, K1 1012 r unsigned long Number of switchings per capacitor stage
Switchings, K2 1016 r unsigned long (0 .. 4 200 000 000)
...
Switchings, K12 1056 r unsigned long
Connect. time, K1 1060 r unsigned long Total connection time per capacitor stage in
Connect. time, K2 1064 r unsigned long seconds. (0 .. 4 200 000 000)
...
Connect. time, K12 1104 r unsigned long
Outputs, remote 2000 w word Bit 0 K1 (1=On, 0=Off)
Bit 1 K2
Bit 2 K3
.. ..
Bit 11 K12
Bit 12 free
Bit 13 Tariff
Bit 14 Remote Tarif
Bit 15 Remote Outputs
1. Harmonic, I 1108 r word mA 16 Bit, 0..5000mA
3. Harmonic, I 1110 r word mA 16 Bit, 0..5000mA
...
19. Harmonic, I 1126 r word mA 16 Bit, 0..5000mA
1. Harmonic, U 1128 r word 0,1V 16 Bit, Unit 0.1Volt
3. Harmonic, U 1130 r word 0,1V 16 Bit, Unit 0.1Volt
...
19. Harmonic, U 1146 r word 0,1V 16 Bit, Unit 0.1Volt
Current transformer ratio 1148 r word 16Bit
Voltage transformer
Primary 1150 r word 16Bit
Attention!
The current and voltage transformer ratios have not been respected at the statements for the measured values.
