Page 53
Reactive Power Controller
= Key 1 = Key 2 = Key 3
Target-cos(phi1) 0.80cap. .. 1.00 .. 0.80ind. 0.96ind
Target-cos(phi2) 0.80cap. .. 1.00 .. 0.80ind. 0.90ind
CT ratio 1 .. 9999 10
Learning of configuration oN, oFF oFF
Stage power of 1. stage 0var .. 9999kvar 10kvar
Stage ratio 0 .. 9 1:1:1:1
Switching outputs 1 .. 12 all stages
Fix stages 0 .. 3 0 = no fix stages
Discharge time 0 .. 1200 seconds 60 Sec.
Disconnection pause for relay stages 0 .. 1200 seconds 40 Sec.
Switching frequency for semic. stages 0.1, 0.2, 0.5, 1.0, 10.0, 50.0Hz
1)
1.0 Hz
Power station service on, oFF oFF
Stage power, 1. - 12. capacitor stages 0var .. 9999kvar 10kvar
Choke degree 0 .. 15% 0 %
VT ratio
Number 1 (Primary) 1 .. 9.999k 1
Number 2 (Secondary) 1, 10, 100, 110, 200, 230, 400 1
Harmonic table number 0 .. 10 0
Alarm calls
Low voltage on/1, oFF oFF
Overvoltage on/2, oFF oFF
Current too low on/3, oFF oFF
Current too high on/4, oFF oFF
Insufficient capacitor power on/5, oFF oFF
Supply of real work on/6, oFF oFF
Harmonic limits exceeded on/7, oFF oFF
Overtemperature on/8, oFF oFF
2)
Averaging time of reactive power 0.1, 0.5, 1.0, 5.0, 10.0, 30.0, 60.0Sek. 60.00 Sec.
Averaging time for mean value cos(phi) 0.25, 0.50, 1.00, 2.00, 12.00, 24.00h 24.00 h
Ventilator control
Upper temperature limit 0 .. 99°C 0°C
Lower temperature limit 0 .. 98°C 0°C
Output number 0 .. 13 (13 = alarm output) 0 = no ventilator control
Overtemperature disconnection
Upper limit 0 .. 99°C 55°C
Lower limit 0 .. 98°C 50°C
Pause time 0 .. 1200 seconds 600 seconds
Indication in manual mode CoS = cos(phi), CAr = react. power CAr = react. power
Password 0 .. 9999 0000 = no password
Contrast 1 .. 12 6
Reset programming
Connection configuration 0° .. 359° 000°
Software Release x.xxx actual version
Serial number part 1 xxxx depending on device
Serial number part 2 xxxx depending on device
Serial interface
Device address 0 .. 126 001
Protocol 0 .. 1 0
Baud rate
Modbus RTU 0=9.6, 1=19.2, 2=38.4, 3=57.6, 4=115.2 0 ( = 9.6kbps)
Profibus DP V0 Automatical adaption up to 1.5Mbps at maximum
Configuration data
Manufacturer's presetting
Setting rangeDescription
Standard programmingExpanded programming
1)
For inner temperatures of over 70°C an alarm is always raised.
2)
If a switching frequency of 50Hz is programmed for the transistor outputs, the serial interface does not work!
