janitza UMG 104 User Manual

63
UMG 104
Power supply voltage
The supply voltage to the UMG104 must be connected through a UL/IEC approved fuse (6A
Char. B).
Option 230V
Nominal range : 95V .. 240V (50/60 Hz) or DC 135V .. 340V
Operating range : +-10% of nominal range
Installation overvoltage category : 300V CATII
Power consumption : max 3.2W, max 9VA
Option 90V (without UL approval)
Nominal range : 50V .. 110V (50/60 Hz) or DC 50V .. 155V
Operating range : +-10% of nominal range
Installation overvoltage category : 300V CATII
Power consumption : max 3.2W, max 9VA
Option 24V
Nominal range : 20V .. 50V (50/60 Hz) or DC 20V .. 70V
Operating range : +-10% of nominal range
Installation overvoltage category : 150V CATII
Power consumption : max 5W, max 8VA
Connectable conductors
Only one conductor may be connected per terminal connection!
Solid core, multi-core, flexible core : 0.08 - 2,5 mm
2, AWG 28 - 12
Pin-end connector, wire end ferrules : 1.5 mm
2
,
AWG 16
