11. 5 RS232 configuration
The following data must be programmed to
operate the RS232 interface:
• baud rate,
• operating mode.
For information on the factory default setting
and the setting ranges, see the parameter list
in section “17. Parameter list”.
Address Settings
201 Baud rate, RS232
0 = 9600Bit/s
1 = 19200Bit/s
2 = 38400Bit/s
3 = 57600Bit/s
4 =115200Bit/s
204 RS232. mode
0 = Modbus RTU/slave
3 = Debug
6 = SLIP
(for internal use only)
Address Settings
200 Device address (1 to 255)
applies to Modbus and Profibus
1 = factory default setting
202 Baud rate, RS485
0 = 9600Bit/s
1 = 19200Bit/s
2 = 38400Bit/s
3 = 57600Bit/s
4 =115200Bit/s
5 = 921600Bit/s
203 RS485, mode
0 = Modbus RTU/slave
1 = Modbus RTU/master
2 = Gateway transparent
11. 6 RS485 configuration
The following data must be programmed to
operate the RS485 interface:
• device address,
• baud rate,
• operating mode,
For information on the factory default setting
and the setting ranges, see the parameter list
in section “17. Parameter list”.
