www.janitza.de
UMG 604-PRO
72
Address Designation Setting range Unit Default
100 Collect TFTP configuration file
automatically
0 = deactivated
x = file number
0 to 9999 - 0
101 TFTP error handling
0 = in the event of an error, the
configuration menu is shown on
the display.
1 = TFTP error handling in the
device is deactivated
0 to 1 - 0
110 Current transformer switch
(L1 to L3)
0 = three current transformers
1 = two current transformers
(Aron circuit)
0 to 1 - 0
111 Voltage measurement network
configuration
0 = three-phase 4-conductor
system (TT, TN network)
1 = three-phase 3-conductor
system (IT network)
0 to 1 - 0
112 Deletes all active energy counters,
apparent energy counters and S0
counters (1 = delete)
0 to 1 - 0
113 Deletes all reactive energy
counters (1 = delete)
0 to 1 - 0
114 Resets all min. and max. values
(1 = reset)
0 to 1 - 0
Table Parameter list for measurement settings
