21
⁄1 Raise the looper threader lever until it clicks into
place.
!6 Looper threader lever
!6
⁄1
!6
⁄2
!7
!8
!9
@1
@0
⁄3
⁄4
@2
⁄5
o
⁄2 Lower the looper threader lever until it knocks into
place.
⁄3 Make sure that the thread comes out from the hole of
the lower looper tip.
!7 Thread end
!8 Hole of lower looper tip
* If the thread does not come out from the hole,
follow the procedure from step ⁄1 again.
* If the thread comes out behind the pipe, use the
tweezers to draw the thread toward you between
the lower looper and the pipe.
!9 Thread (behind the pipe)
@0 Pipe
@1 Lower looper
⁄4 Draw 4˝ (10 cm) of the thread under the toe of the foot,
and pull it to the rear between the foot and the upper
knife.
@2 Upper knife
⁄5 Return the lower threader switch lever to the “SEWING”
position.
o Lower threader switch lever
Close the looper cover and lower the presser foot
lifter.
