SECTION 1 PREPARATION
Names of Parts
1 Visual touch screen
2 Thread guide indication
3 Pressure adjusting dial
4 Screen sharpness adjusting knob
5 Up/Down needle position key
6 Side cover
7 Looper cover
8 Handwheel
9 Power switch
10 Differential feed dial
11 Stitch length dial
12 Extension table (A)
13 Double chain looper
14 Lower looper
15 Upper looper
16 Upper knife
17 Chaining finger setting knob
18 Presser foot
19 Needle plate
20 Cutting width adjusting dial
21 Upper knife release knob
