Janome CompuLock - Opening and Closing the Looper Cover; The Position of Telescoping Thread Guide Bar

7
Opening and Closing the Looper Cover
1 Looper cover
The Position of Telescoping Thread
Guide Bar
1 Telescoping thread guide bar
2 Stoppers
3 Spool pin
4 Thread guide
1
1
2
3
To open:
While pushing with the thumb to the right as far
as it will go, pull looper cover toward you.
To close:
Lift looper cover and push against the machine.
The looper cover snaps into the position
automatically.
1 Pull the telescoping thread guide bar
up as far as it will go.
2 Turn the thread guide bar until it clicks
into position.
Thread guides should stop directly
above the spool pins.
4
1 , 2
