Janome HD718 - Stretch Stitch Balance

14
MECHANICAL ADJUSTMENT
STRETCH STITCH BALANCE
TO CHECK:
1. Set the stitch selector at . Set the stitch length dial at S.S. position, and stretch stitch adjuster
at " ".
2. Place a piece of paper on the needle plate and lower the presser foot.
3 Turn the handwheel to mark needle points on the paper.
4. The needle should penetrate the same holes in forward and reverse direction while turning
the handwheel towards you.
SELECTED PATTERN STITCH LENGTH DIAL
