Janome HD718 - Oiling

30
A
B
C
D
E
F
G
H
I
J
OILING
Factory lubricated parts will provide years of household sewing without routine oiling.
However, whenever the machine is being serviced, check to see if any parts needs to be
lubricated.
OIL:
Use good quality sewing machine oil at the points (A, B, C, D, E, F & G) indicated by the black
arrows.
GREASE:
Use white grease such as "Molycote EM-40M" at the points (H, I, & J) indicated by the white
arrows.
