Janome HD718 - Base Plate; Bed Cover

5
SERVICE ACCESS
BASE PLATE
1. Remove 4 setscrews (A).
2. Remove the base plate (B).
BED COVER
1. Remove 2 setscrews (D).
2. Remove the bed cover (E).
* When you replace the bed cover, set the drop lever (F) in the left position as illustrated.
(A)
(A)
(A)
(A)
(B)
(D)
(E)
(F)
