66
unit (or use a ratchet to actuate the motor) to pull the room in or out.
1. Locate the included exible shaft in your
owner’s packet.
2. Attach exible shaft to the 1/4” hex tting
on the end of the motor.
3. Attach 1/4” socket & ratchet, or drill to the
other end, and turn in the proper direction
to move the room.
4. If the cables tighten, and the motor
is dicult to turn, REVERSE THE
DIRECTION.
- The slideout system is equipped with a manual override that allows you
to extend or retract the room in the event of a loss of power.
Always disconnect battery from system prior to manually operating
system. Failure to disconnect battery can cause electricity to back feed
through the motor and cause serious damage to the system as well as void
the warranty
. The gears can be stripped out if the
room is manually retracted/extended to its fullest extent and the operator
continues to rotate manual override. Damage can also occur to the slide
components, slide room structure or trim components. Damages due to
misuse of the manual override feature will void any and all claims to the
Limited Warranty.
