Speaker System:
ScreenArray
TM
3632-T (Tri-Amp)
Date: 3/4/2003
DSC260
Parameter
Input A
Input B
Input A+B
Input Delay
Input EQ1 Type Bell* Bell*
Input EQ1 Frequency 50.7 50.7
Input EQ1 +/- 3.0 3.0
Input EQ1 Bandwidth 0.60 0.60
Input EQ2 Type
Input EQ2 Frequency
Input EQ2 +/-
Input EQ2 Bandwidth
Input EQ3 Type
Input EQ3 Frequency
Input EQ3 +/-
Input EQ3 Bandwidth
Input EQ4 Type
Input EQ4 Frequency
Input EQ4 +/-
Input EQ4 Bandwidth
Input EQ4 Type
Input EQ4 Frequency
Input EQ4 +/-
Input EQ4 Bandwidth
Parameter
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output Name
L LOW
L MID
L HI
R LOW
R MID
R HI
Output Source A A A B B B
Output Gain 1.0 -4.0 -11.0 1.0 -4.0 -10.0
Output Limit 10.0 10.0 10.0 10.0 10.0 10.0
Output Delay 1.582 0.125 0.000 1.582 0.125 0.000
Output Delay Link Off Off Off Off Off Off
Polarity Normal Normal Normal Normal Normal Normal
Output Lo Shape L-R12 L-R24 BUT18 L-R12 L-R24 BUT18
Output Lo Frequency 25.0 450.0 1.31k 25.0 450.0 1.31k
Output Hi Shape L-R24 BUT18 BUT12 L-R24 BUT18 BUT12
Output Hi Frequency 353.0 1.46k Out 353.0 1.46k Out
Output EQ1 Type Bell Bell Bell Bell Bell Bell
Output EQ1 Frequency 176.0 707.0 2.37k 176.0 707.0 2.37k
Output EQ1 +/- -5.0 -3.0 -2.0 -5.0 -3.0 -2.0
Output EQ1 Bandwidth 0.35 0.55 1.00 0.35 0.55 1.00
Output EQ2 Type Bell Bell Bell Bell Bell Bell
Output EQ2 Frequency 341.0 2.54k 4.43k 341.0 2.54k 4.43k
Output EQ2 +/- 3.0 -9.0 3.0 3.0 -9.0 3.0
Output EQ2 Bandwidth 0.35 0.50 0.25 0.35 0.50 0.25
Output EQ3Type Hi12 Hi12
Output EQ3 Frequency 8.57k 8.57k
Output EQ3 +/- 14.0 14.0
Output EQ3 Bandwidth
Output EQ4 Type
Output EQ4 Frequency
Output EQ4 +/-
Output EQ4 Bandwidth
(*) Set this filter to "0.0dB" if system is installed in a full baffle wall
Page 1
Recommended signal processing settings for DSC260A Digital System Controller.
See www.jblpro.com for most current processor settings
