JBL Cinema 300 - Page 41

41
Speaker System:
ScreenArray
TM
4632 (Bi-Amp)
Date: 3/4/2003
DSC260
Parameter
Input A
Input B
Input A+B
Input Delay
Input EQ1 Type Bell* Bell*
Input EQ1 Frequency 50.7 50.7
Input EQ1 +/- 3.0 3.0
Input EQ1 Bandwidth 0.60 0.60
Input EQ2 Type
Input EQ2 Frequency
Input EQ2 +/-
Input EQ2 Bandwidth
Input EQ3 Type
Input EQ3 Frequency
Input EQ3 +/-
Input EQ3 Bandwidth
Input EQ4 Type
Input EQ4 Frequency
Input EQ4 +/-
Input EQ4 Bandwidth
Input EQ4 Type
Input EQ4 Frequency
Input EQ4 +/-
Input EQ4 Bandwidth
Parameter
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output Name
USUSED
L LOW
L MID+HI
UNUSED
R LOW
R MID+HI
Output Source A A B B
Output Gain -2.0 -7.0 -2.0 -7.0
Output Limit 10.0 10.0 10.0 10.0
Output Delay 0.354 0.000 0.354 0.000
Output Delay Link Off Off Off Off
Polarity Normal Normal Normal Normal
Output Lo Shape BUT12 BUT48 BUT12 BUT48
Output Lo Frequency 30.1 250.0 30.1 250.0
Output Hi Shape BUT48 BUT12 BUT48 BUT12
Output Hi Frequency 225.0 Out 225.0 Out
Output EQ1 Type Bell Bell Bell Bell
Output EQ1 Frequency 138.0 307.0 138.0 307.0
Output EQ1 +/- -3.0 3.0 -3.0 3.0
Output EQ1 Bandwidth 0.45 0.30 0.45 0.30
Output EQ2 Type Bell Bell
Output EQ2 Frequency 637.0 637.0
Output EQ2 +/- 3.5 3.5
Output EQ2 Bandwidth 0.15 0.15
Output EQ3Type Hi12 Hi12
Output EQ3 Frequency 10.1k 10.1k
Output EQ3 +/- 9.0 9.0
Output EQ3 Bandwidth
Output EQ4 Type
Output EQ4 Frequency
Output EQ4 +/-
Output EQ4 Bandwidth
(*) Set this filter to "0.0dB" if system is installed in a full baffle wall
Page 1
Recommended signal processing settings for DSC260A Digital System Controller.
See www.jblpro.com for most current processor settings
