AUREUS TMS320DA610, TMS320DA601
FLOATING-POINT DIGITAL SIGNAL PROCESSORS
POST OFFICE BOX 1443 • HOUSTON, TEXAS 77251−1443
D Aureus High-Performance 32-/64-Bit
Audio Digital Signal Processors (DSPs)
D DA610-250 MHz, 2000 MIPS/1500 MFLOPS
D DA601-225 MHz, 1800 MIPS/1350 MFLOPS
D Single DSP Solutions for Multichannel
Audio Applications: A/V and DVD
Receivers, Multi-Zone Receivers, High
Speed Encoder, Simultaneous
Encode/Decode, Surround Headphone,
Speaker Virtualization, Room Correction
D DA601 and DA610 Compatibility Provides a
Scalable Audio Solution Based on a Single
DSP Instruction Set Architecture
D Certified Algorithms:
− Dolby Digital Decoder, Dolby Digital EX,
Dolby Pro Logic IIx, Dolby Pro Logic II
− DTS 5.1, DTS−ES 6.1, DTS Neo:6,
DTS 96/24
− MPEG−2 AAC
− THX Ultra 2
D Supports Other Algorithms Including:
− MP3 CODEC
− WMA CODEC
− SRS Circle Surround II
− Waves’ MaxxBass Technology
D Highly Optimized C/C++ Compiler
D VelociTI Advanced Very Long Instruction
Word (VLIW) C67x DSP Core
− Native Instruction Set Support for:
− 32-/64-Bit IEEE 754 Floating-Point
− 32/40/64 & Packed-16-Bit Fixed-Point
− Eight Independent Functional Units:
− Two ALUs (Fixed-Point)
− Four ALUs (Floating- and Fixed-Point)
− Two Multipliers (Floating-/Fixed-Point)
− Fast Time to Market with RISC−Like ISA
D Low-Cost, Two-Level Memory System
− 4K-Byte L1P Plus 4K-Byte L1D Cache
− 256K-Byte L2 Cache/RAM (DA610)
− 128K-Byte L2 Cache/RAM (DA601)
− 512K-Byte L2 ROM (DA610/DA601)
D 32-Bit External Memory Interface (EMIF)
Seamlessly Expands Memory Space by
Supporting: SRAM, SDRAM, FLASH,
EPROM, and SBSRAM.
Four External Address Spaces
D 16-Bit Host-Port Interface (HPI) Enables
High-Speed Encode/Decode Applications
D Enhanced Direct-Memory-Access (EDMA)
Controller With 16 Independent Channels
D Two Multichannel Audio Serial Ports
(McASPs)
− Independent Dual Zone Audio on a
Single DSP
− 16 Data Pins (32 Channel Stereo)
− Flexible Clocking
− TDM Streams 2-32 Channels per Pin
− Data Formatting Unit Supports Wide
Variety of I2S and Similar Formats
− Integrated Digital Audio Interface
Transmitter (DIT) With Enhanced
Channel Status/User Data
− Extensive Error Checking and Recovery
D Two Inter-Integrated Circuit Bus (I
2
C Bus)
Multi-Master and Slave Interfaces
D Two Multichannel Buffered Serial Ports
(McBSPs) Supporting:
− Serial-Peripheral-Interface (SPI)
− High-Speed TDM Interface
D Two 32-Bit General-Purpose Timers
D Two General-Purpose Input/Output
Modules
D On-Chip Oscillator and PLL Module
D IEEE-1149.1 (JTAG
†
)
Boundary-Scan-Compatible
D Package Options:
− 208-Pin PowerPAD PQFP (PYP Suffix)
− 272-Pin Ball Grid Array (GDP Suffix)
D 0.13-µm Copper Metal CMOS Process
D 3.3-V I/Os, 1.2-V Internal
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications o
Copyright 2005, Texas Instruments Incorporated
Aureus, VelociTI, C67x, and PowerPAD are trademarks of Texas Instruments.
All trademarks are the property of their respective owners.
†
IEEE Standard 1149.1-1990 Standard-Test-Access Port and Boundary Scan Architecture.
