Harness Drawing - Side Console, page 3 of 5 - CAD 721/10970 Issue 2
(Machines from serial no. 933757)
153 - 7
Section C Electrics
9803/3280
Section C
153 - 7
Issue 1
Harness Data
Key to Connectors:
CB Cab Link
CU Ignition Switch (CU1)
CV Instrument Panel
CW Fuel Gauge
CWA Fuel Gauge Illium
CX Water Temperature Gauge
CXA Water Temperature Illium
CY Tachometer
CYA Tachometer Illium A
CYB Tachometer Illium B
CZ Radio Cassette
DA Radio Speaker
DC Front Work Light Switch
DD Beacon Switch
DE Hydraulic Speed Control Switch
DF Smooth Ride System Switch
DG Shovel Reset
DH Rear Work Light Switch
DJ Rear Wash/Wipe Switch
DK Auxiliary Hydraulic Switch
DL Hydraclamp Switch
DM Rear Wiper
DN Work Light Diode
DS Heater Unit
DX Cigar Lighter
DY Dallas Key
EA Immobiliser
EAB Immobiliser Link
EB Exciter Diode
EBA Exciter Link
